Yuyao Ollin Photovoltaic Technology Co., Ltd.

Home ProductsSolar Panel Solar Cell

Fish Pond System Solar Panel Solar Cell / Monocrystalline Solar Panels

Fish Pond System Solar Panel Solar Cell / Monocrystalline Solar Panels

  • Fish Pond System Solar Panel Solar Cell / Monocrystalline Solar Panels
Fish Pond System Solar Panel Solar Cell / Monocrystalline Solar Panels
Product Details:
Place of Origin: zhejiang Pr, China
Brand Name: OLLIN PV
Certification: CE ROSH ISO
Model Number: OL-36m-155
Payment & Shipping Terms:
Minimum Order Quantity: one unit
Price: Negotiable
Packaging Details: 2 PCS PER CARTON OR 25PCS PER PALLET
Delivery Time: 20DAYS
Supply Ability: 1500UNITS PER WEEK
Contact Now
Detailed Product Description
Cell Material: Monocrystalline Silicon Cell Array: 4*9
Cell Color: Black Frame: Anodized Aluminum Alloy
Front Sheet: High Transmissions Low Iron Tempered Glass Back Sheet: TPE Quality Plastic
Main Market: Asia Africa Southeast Asia Junction Box: JB With 0.9m Wire And Connector
High Light:

solar power plate

,

building solar panels

Solar Panel Solar Cell Fish pond system 155W monocrystalline Solar Panel white frame and sheet

Poly Solar panel



High efficiency mono solar cell with positive tolerance only


International quality management system with 100% panel power and EL test before shipment


Fire test, Salt mist corrosion resistance approved


Nearest shipment port: Ningbo or Shanghai


Temperature Coefficients:



Power temperature coefficient (%/ºC): - 0.45 %/ºC


Current temperature coefficient(%/ºC): 0.065±0.015 %/ºC


Voltage temperature coefficient(%/ºC): - 0.35 %/ºC


NOCT-Normal Operating Cell Temperature: 45±2ºC





Electrical Characteristics



Module Type OLPV130W OLPV140W OLPV150W OLPV160W OLPV165W
Maximum power 130 W 140 W 150 W 160 W 165 W
Max power voltage 17.50 V 17.70 V 17.90 V 18.10 V 18.20 V
Max power current 7.43 A 7.92 A 8.38 A 8.84 A 9.06 A
Open circuit voltage 21.50 V 21.70 V 21.90 V 22.10 V 22.30 V
Short circuit current 7.96 A 8.49 A 9.01 A 9.53 A 9.74 A
Module Efficiency 13.13% 14.14% 15.15% 16.16% 16.67%
Power Tolerance -0~+5W -0~+5W -0~+5W -0~+5W -0~+5W
Standard Test Conditions (STC): Irradiance 1000W/m2, Module temperature 25℃? Air Mass (AM)=1.5
Nominal Operating Cell Temperatur 45 ± 2℃
Temperature coefficients of Isc +0.049% /℃
Temperature coefficients of Voc -0.340% /℃
Temperature coefficients of Pmax -0.430% /℃
Solar Cell Poly solar cells 156x156 mm
Front Cover 3.2 mm thick, tempered glass
Back Cover TPT (Tedlar-PET-Tedlar)
Encapsulant EVA (ethylene vinyl acetate)
Frame Double-layer anodized aluminium alloy
Junction Box IP65 rated
Maximum System Voltage DC1000V (IEC)
Maximum Series Fuse 15 A
Operating Temperature -40℃~+85℃
Storage Temperature -40℃~+85℃
Max. Wind Load / Max. Snow Load 2400Pa / 5400Pa
Application Class Class A
Packing configuration Carton.Customers packing requirement is acceptable.

Fish Pond System Solar Panel Solar Cell / Monocrystalline Solar Panels 0





Company Profile:



We are a professional manufacturer specialized in Solar Panels with more than 8 years of experience. Our



main products include: Mono and Poly Solar Panel, Solar power system, Solar charger controller, Inverters, Solar LED lights, and so on.



What we can provide: High quality and very competitive price, fast delivery and best service!



A trustable and reliable supplier for your business. We have already exported our products around the world includes Russian, Middle East, South American, Southeast Asia and so on.



For any details, please don't hesitate to contact me any time!



RFQ



Q1 Are you a factory or trading company?



A Yes, we are factory, supplying OEM/ODM service.



Q2 Can you accept OEM service?



A Yes, we can. Qty is not the only standard , more qty, less cost.



Q3 How about your after sales-service?



A 1.Guarantee time: one year, but solar panel 3 years



2.Spare parts:1% spare parts will be shipped with your order.



Q4 How about your payment terms?



A We accept T/T, LC



Q5 What certification do you have?



A 1. CE, 2.According to your need , do the certification or report , if you have a big order.



Q6 How many day about delivery time?



A 1. Sample delivered in 3-5 days.



2. Order delivered in 15-20 days.



Q7 Which port shipping goods?



Ningbo port/ shanghai port/yiwu port
