| Brand Name: | OEM |
| Model Number: | OEM |
| MOQ: | 1unit |
| Price: | Negotiable |
| Delivery Time: | 20days |
On grid 10kw home solar generation power system Residential Solar Power Systems
The Size of Your Solar PV System
The size of your solar system depends on several factors such as how much electricity or hot water or
space heat you use, the size of your roof, how much you're willing to invest, and how much energy you
want to generate. Contact a system designer / installer to determine what type of system fits your needs.
| 1.1KW Grid Tied Solar System Specification | ||
| SOLAR PANEL | ||
| Solar panel power Pm | 12*260WP | |
| Power allowance | ±3% | |
| Optimized working voltage Vm | 36.6V | |
| Optimized working current Im | 7.1A | |
| Open circuit voltage Voc | 45.1V | |
| Short circuit current Isc | 7.67A | |
| GRID TIED INVERTER | ||
| Inverter Input (DC) | ||
| Max. DC power | 3100W | |
| Max. DC voltage | 500V | |
| Max. input current | 8.8A | |
| Number of MPP trackers/Strings per MPP tracker | 1 1 | |
| MPPT voltage range (at rated power) | 120～425V | |
| Shutdown voltage/Start voltage | 70/120V | |
| Inverter Output (AC) | Inverter Output (AC) | |
| AC nominal power | 3000W | |
| Max. AC power | 1000W | |
| Max. AC current | 5.5A | |
| Nominal AC voltage / range | 230 / 180~270V | |
| AC grid frequency / range | 50 / 47~52Hz | |
| Power factor (cosφ) | 1 | |
| Total harmonic distortion (THDi)(at nominal power) | <3% | |
| Inverter Efficiency | Inverter Efficiency | |
| Max. efficiency | 96.60% | |
| Euro efficiency | 95.50% | |
| MPPT efficiency | 99.90% | |
| Inverter General data | ||
| Dimensions (W / H / D) | 285*385*145mm | |
| Weight [kg] | 15Kg | |
| Operating temperature range | -20～+60 (derating at 45 °C) | |
| Ingress protection | IP65 | |
| Topology | transformerless | |
| Internal consumption(night) | 0 | |
| Cooling concept | Convection | |
| Noise (typical) | <30 dB | |
| LCD display | Backlight, 16*2 Character LCD | |
| Communication port | RS232 | |
| SOLAR PANEL MOUNTING(Pitch roof ) | ||
| Rail | 2600mm*8pcs | |
| Hook | 24pcs | |
| Middle clamp | 20pcs | |
| End clamp | 8pcs | |
| Connect of rail | 4pcs | |
| Grounding lug (Optional) | 10pcs | |
| Earthing clips (Optional) | 10pcs | |
| ELERTRIC BOX (Optional) | AC/DC Circuit Breakers,Lighting arrestors, Electric meter | |
Solar Panel Modules for Off-Grid Homes
Solar modules essentially work like a car battery charger, except instead of plugging it into the wall, you put
it out directly in the sun. How do solar modules work, and why should you consider an off grid power
systems?
Our Promise to You
Every one of our techs lives with at least some of the products that we feature on our website and in our
catalog. When you order from us, you're not just getting products we believe in, you're getting life-long
support from our team of experts. Your questions will get answered and your needs will be met. It is our
earnest goal to leave you completely satisfied.
We offer FREE custom design service for your alternative energy system as well as FREE after-sale
technical support for the life of the system - it's what has helped make us America's most trusted off-grid
power supplier. Let us work for you!
video
video
video
video
|
|
