Product Details:
|
| Material: | Polycrystalline Silicon | Color: | Dark Blue |
|---|---|---|---|
| Dimension: | OEM | Frame: | NO FRAME |
| Epoxy: | Solar Panels | Square: | Square |
| High Light: | mini solar panels,mini solar cell |
||
Features
1. The surface is sealed with high-performance epoxy resin polyester film;
2. High conversion efficiency based on leading innovative photovoltaic technologies;
3. High stabillity with guaranteed+/-3%power output tolerance, ensuring return on investment;
4. Beautiful appearance;
5. Withstands high wind-pressure and snow load;
6. Easy to install.
| Item No. | Max Power | Rated Voltage | Output Voltage | Dimension | Net Weight |
| 0.5V100MA | 0.05W | 0.5VDC | 53x18x3mm | 0.003kg | |
| 1V85MA | 0.085W | 1VDC | 30x25x3mm | 0.0022kg | |
| 1.5V400MA | 0.65W | 1.5VDC | Charge for 1.2V Battery | 80x60x3mm | 0.018kg |
| 2V130MA | 0.26W | 2VDC | 54x54x3mm | 0.009kg | |
| 2V50MA | 0.1W | 50x34x3mm | 0.008kg | ||
| 3V120MA | 0.36W | 3VDC | 60x55x3mm | 0.011kg | |
| 5V30MA | 0.15W | 5-5.5VDC | Charge for 3.6V-3.7V Battery | 53x30x3mm | 0.005kg |
| 5V60MA | 0.3W | 68x36x3mm | 0.01kg | ||
| 5V150MA | 0.75W | 99x69x3mm | 0.02kg | ||
| 5.5V50MA | 80x35x3mm | 0.01kg | |||
| 5.5V60MA | 0.3W | 100x28x3mm | 0.01kg | ||
| 5.5V100MA | 0.55W | 84.5x55.5x3mm | 0.018kg | ||
| 5.5V120MA | 0.66W | 80x60x3mm | 0.02kg | ||
| 6.5V90MA | 0.6W | 6-6.5VDC | 120x70x3mm | 0.03kg | |
| 6V100MA | 0.6W | 120x38x3mm | 0.016kg | ||
| 6V330MA | 2W | 136x110x3mm | 0.06kg | ||
| 6V500MA | 3W | 145x145x3mm | 0.07kg | ||
| 6V580MA | 3.5W | 135x165x3mm | 0.077kg | ||
| 6V750MA | 4.5W | 145x145x3mm | 0.07kg |
Tips: How to choose mini solar panels
This table shows the solar system configuration relationship between storage batteries and mini solar panels.
| DC Storage Battery | Mini Solar Panel |
| 1.2V | 2V ~ 2.5V |
| 2.4V | 3.5V ~ 4V |
| 3.6V | 5V ~ 6V |
| 3.7V | 5.5V-6V |
| 4V | 6-7V |
| 4.8V | 7-8V |
| 6V | 8V ~ 9V |
| 12V | 16V ~ 18V |
FAQ
1. Q: How do I pay for my purchase order?
A: T/T, L/C, Paypal at sight.
2. Q: How can I get sample and how long will it takes?
A: Samples will charge, but we can apply to return in the further order. It usually takes 6-8 days to produce
the samples.
3. Q: What's the MOQ?
A: Depend customer's demand.
4. Q: What's the time delivery?
A: It will take about 10-15 days to finish an order. But the exact time is according to actual situation.
5. Q: Can I have my own customized product?
A: Yes, your customized requirements for color, logo, design, package,shipping marks etc are available
