| Brand Name: | OLLIN PV |
| Model Number: | OEM |
| MOQ: | 1set |
| Price: | negotiation |
| Delivery Time: | 20days |
Features of the solar street light:
1. Very easy to install, IP65 Waterproof and stunning quality for outdoor and indoor flood light.
2. Provide bright and wide beam distribution light for general purpose flood night lighting.
3. Energy-saving and Eco-friendly, no any pollution to environment.
4. High efficiency, low light decay.
Electrical Characteristics
Maximum Power (Pm) :1.9W
Operating Voltage (Vmp):6V
Operating Current (Imp) :105mA
Power Tolerance:-5% to +5%
Dimension: Diameter:160mm, thinkness:5mm
Panel color: White
Glass thickness:3.2mm,Low iron tempered glass
Type:Monocrystalline silicon solar cell
Encapsulation Methods: Glass Lamination Solar panel
No frame, without junction box, with solder wire
Warranty: nominal power keep
| Standard Test Conditions (STC): Irradiance 1000W/m2, Module temperature 25℃? Air Mass (AM)=1.5 | |||||
| Nominal Operating Cell Temperatur | 45 ± 2℃ | ||||
| Temperature coefficients of Isc | +0.049% /℃ | ||||
| Temperature coefficients of Voc | -0.340% /℃ | ||||
| Temperature coefficients of Pmax | -0.430% /℃ | ||||
| Solar Cell | Poly solar cells 156x156 mm | ||||
| Front Cover | 3.2 mm thick, tempered glass | ||||
| Back Cover | TPT (Tedlar-PET-Tedlar) | ||||
| Encapsulant | EVA (ethylene vinyl acetate) | ||||
| Frame | Double-layer anodized aluminium alloy | ||||
| Junction Box | IP65 rated | ||||
| Maximum System Voltage | DC1000V (IEC) | ||||
| Maximum Series Fuse | 15 A | ||||
| Operating Temperature | -40℃~+85℃ | ||||
| Storage Temperature | -40℃~+85℃ | ||||
| Max. Wind Load / Max. Snow Load | 2400Pa / 5400Pa | ||||
| Application Class | Class A | ||||
| Packing configuration | Carton.Customers packing requirement is acceptable. | ||||
How Do Solar Panels Work?
When photons hit a solar cell, they knock electrons loose from their atoms. If conductors are attached to
the positive and negative sides of a cell, it forms an electrical circuit. When electrons flow through such a
circuit, they generate electricity. Multiple cells make up a solar panel, and multiple panels (modules) can be
wired together to form a solar array. The more panels you can deploy, the more energy you can expect to
generate.
What are Solar Panels Made of?
Photovoltaic (PV) solar panels are made up of many solar cells. Solar cells are made of silicon, like
semiconductors. They are constructed with a positive layer and a negative layer, which together create an
electric field, just like in a battery.
Company Profile:
We are a professional manufacturer specialized in Solar Panels with more than 8 years of experience. Our
main products include: Mono and Poly Solar Panel, Solar power system, Solar charger controller, Inverters,
Solar LED lights, and so on.
What we can provide: High quality and very competitive price, fast delivery and best service!
WHY CHOOSE US?
1. Excellent efficiency, Easy Installation & Maintenance
2. Outstanding performance in Low-Light
3. High transparent, Low-Iron, Tempered Glass
4. Ability to withstand High Wind-Pressure and Snow-Load
5. Advanced module sealing technology to eliminate leakage and frame deformation
6. Ability to meet customized customer's specific requirements
|
|
| Brand Name: | OLLIN PV |
| Model Number: | OEM |
| MOQ: | 1set |
| Price: | negotiation |
| Packaging Details: | pallet |
Features of the solar street light:
1. Very easy to install, IP65 Waterproof and stunning quality for outdoor and indoor flood light.
2. Provide bright and wide beam distribution light for general purpose flood night lighting.
3. Energy-saving and Eco-friendly, no any pollution to environment.
4. High efficiency, low light decay.
Electrical Characteristics
Maximum Power (Pm) :1.9W
Operating Voltage (Vmp):6V
Operating Current (Imp) :105mA
Power Tolerance:-5% to +5%
Dimension: Diameter:160mm, thinkness:5mm
Panel color: White
Glass thickness:3.2mm,Low iron tempered glass
Type:Monocrystalline silicon solar cell
Encapsulation Methods: Glass Lamination Solar panel
No frame, without junction box, with solder wire
Warranty: nominal power keep
| Standard Test Conditions (STC): Irradiance 1000W/m2, Module temperature 25℃? Air Mass (AM)=1.5 | |||||
| Nominal Operating Cell Temperatur | 45 ± 2℃ | ||||
| Temperature coefficients of Isc | +0.049% /℃ | ||||
| Temperature coefficients of Voc | -0.340% /℃ | ||||
| Temperature coefficients of Pmax | -0.430% /℃ | ||||
| Solar Cell | Poly solar cells 156x156 mm | ||||
| Front Cover | 3.2 mm thick, tempered glass | ||||
| Back Cover | TPT (Tedlar-PET-Tedlar) | ||||
| Encapsulant | EVA (ethylene vinyl acetate) | ||||
| Frame | Double-layer anodized aluminium alloy | ||||
| Junction Box | IP65 rated | ||||
| Maximum System Voltage | DC1000V (IEC) | ||||
| Maximum Series Fuse | 15 A | ||||
| Operating Temperature | -40℃~+85℃ | ||||
| Storage Temperature | -40℃~+85℃ | ||||
| Max. Wind Load / Max. Snow Load | 2400Pa / 5400Pa | ||||
| Application Class | Class A | ||||
| Packing configuration | Carton.Customers packing requirement is acceptable. | ||||
How Do Solar Panels Work?
When photons hit a solar cell, they knock electrons loose from their atoms. If conductors are attached to
the positive and negative sides of a cell, it forms an electrical circuit. When electrons flow through such a
circuit, they generate electricity. Multiple cells make up a solar panel, and multiple panels (modules) can be
wired together to form a solar array. The more panels you can deploy, the more energy you can expect to
generate.
What are Solar Panels Made of?
Photovoltaic (PV) solar panels are made up of many solar cells. Solar cells are made of silicon, like
semiconductors. They are constructed with a positive layer and a negative layer, which together create an
electric field, just like in a battery.
Company Profile:
We are a professional manufacturer specialized in Solar Panels with more than 8 years of experience. Our
main products include: Mono and Poly Solar Panel, Solar power system, Solar charger controller, Inverters,
Solar LED lights, and so on.
What we can provide: High quality and very competitive price, fast delivery and best service!
WHY CHOOSE US?
1. Excellent efficiency, Easy Installation & Maintenance
2. Outstanding performance in Low-Light
3. High transparent, Low-Iron, Tempered Glass
4. Ability to withstand High Wind-Pressure and Snow-Load
5. Advanced module sealing technology to eliminate leakage and frame deformation
6. Ability to meet customized customer's specific requirements
